Why choose our 12V electrical false floor systems
Turn your cargo space into a clean power hub that looks factory and works all day. Built around Redarc charging with a slim Bluetooth lithium battery, everything mounts to our false floors with tidy wiring and proper protection.
✅ Clean and serviceable install that looks factory
✅ Correct fusing and breakers for reliability on corrugations
✅ Bluetooth battery monitoring in the battery BMS
✅ Vehicle specific layout for a neat fit under or behind the false floor
What is included in the base system
✔ Redarc BCDC Core 40A in cabin DC to DC with solar input
✔ Full wiring kit from start battery to rear battery
✔ Six position fuse panel
✔ Three resettable circuit breakers for DC to DC solar and fuse panel
✔ Cup holder outlet panel with one Anderson one cig socket and one USB C or USB fast charger
Battery choices all with Bluetooth inside the BMS
- ATG 12V 100Ah Slim LiFePO4
Cells A grade prismatic LiFePO4
Continuous discharge 150A
- Custom Lithium Next Generation Ultra Slim 100Ah
Cells A grade automotive LiFePO4
Continuous discharge 180A
- AllSpark Ultra Slim 100Ah
Cells A grade prismatic LiFePO4
Continuous discharge 200A peak 500A
Starter package pricing
ATG 100Ah Supply 3500 Installed 4000
Custom Lithium 100Ah Supply 4000 Installed 4500
AllSpark 100Ah Supply 3900 Installed 4400
Important fitment and installation notes
✔ Designed to mount to our false floors
✔ Vehicle fit Y62 Nissan Patrol, LC300, Prado 250, Prado 150, Ford Everest, Isuzu MUX
✔ Typical install time one day depending on options
✔ DC to DC is in cabin rated
Ordering note
These systems are designed for our false floors. If you are ordering a false floor and want one of these systems add both the false floor and the power system to your cart. Built to order.
For extras or customisations please call after your order has been placed.
Real world performance
All listed batteries have enough capacity to run a 40L Evakool drawer fridge for about three to four days on battery capacity alone with no charge going in. Actual runtime will vary with ambient temperature fridge setpoint packing and airflow.
Each system can also run an ARB twin compressor for tyre inflation and short duty cycles without drama.
